2 Position Heavy Duty Battery Switch, 20A AC

A compact but rugged battery switch capable of handling high current loads

This small battery switch was designed to take a beating. An impact resistant polycarbonate case protects this two position heavy duty battery switch from external abuse and allows installation in the harshest of locations. Heavy Duty copper sweep internals ensure positive circuit control. The alternator field disconnect allows the battery to be accidently turned to the OFF position while the engine is running without damaging alternator diodes. The contoured knob features positive click stops and is designed to allow operation by feel in low or no light situations.

Key Features

• Compact design provides more installation options
• Impact resistant polycarbonate case stands up to external abuse
• Contoured knob allows operation by feel in low or no light situations
• Alternator Field Disconnect allows switch to be accidentally turned to OFF position while the engine is running without damaging alternator diodes
• NOT ignition protected and cannot be installed in engine rooms of gasoline powered boats
• One-year warranty

Specifications

• Switch Positions: 2
• Battery Combine: No
• Alternator Field Disconnect: Yes
• Maximum Voltage: 36V
• Continuous Rating: 600A
• Intermittent Rating (duration): 1000A (5min)
• Cranking Rating (30Sec): N/A
• Battery Inputs: 1
• Cable Size to meet ratings: 1/0 AWG
• Mounting Holes: #10 Screws
• Terminal Stud size: 1/2”
• Dimensions: 3 5/8”L x 3 5/8”W x 2 3/8” H
• Weight: 3 Lbs.
