Trailer Double Eye Springs
Model #
12875308
Mfg #
16420
$71.49
Orders placed by 3 PM EST typically ship the same day. Orders placed after this time will be processed the next business day.
Select a Product:
25 1/8" Double Eye Spring 3 Leaves
Out Of Stock
Item out of stock get notified when back in stock:
Thank you!
We'll let you know when it's back in stock.
Quantity not available. Please adjust.
−
+
Complete Your Purchase
Replace your trailer's worn, sagging leaf springs with new springs from Smith. Trailers are built for a multitude of purposes and the springs under them come in a variety of shapes and sizes with load capacities to match the capacity of the axle and what's being hauled. Order the same size and capacity springs that you are replacing. Note your spring style, double eye or slipper. Slipper ends are either Radiused, Hooked, or Flat. Measure the length, width, height and count the leaves, then find your springs on the chart. Eyes take 9/16" Shackle bolts.
| Double Eye Springs |
|||||||
| Part # | Number of Leaves | Width | Eye to Ctr to Eye Center | Height | Capacity (lbs) per Spring | Spring Weight | End Style |
| 12875316 | 4 | 1.75 | 25.13 | 3.25 | 1830 | 12.2 | Eye |
| 12875340 | 5 | 1.75 | 25.25 | 3.12 | 3000 | 15.73 | Eye |
| 12875332 | 4 | 1.75 | 25.25 | 3 | 2500 | 14.1 | Eye |
| 12875308 | 3 | 1.75 | 25.13 | 3.18 | 1250 | 9.54 | Eye |
| 12875324 | 3 | 1.75 | 25.25 | 3 | 2000 | 11.46 | Eye |
Diameter
9/16 Inch
Dimensions
1 3/4" Width x 3 1/8" Height x 25 1/8" Length
Length
25 1/8 Inches
Type
Springs
