A60 Slimline Fire Damper Actuator

CENTEK A60 Slimline Fire Damper Actuator

The 273-A60-24/240 is a failsafe electrical actuator specifically engineered to operate Delta-T A60-rated Slimline fire dampers. This turnkey system is ready for installation aboard vessels and is designed to meet the needs of modern boat builders and refit yards. The actuator provides 180 in-lb of closing torque and accepts a wide-range electrical input of 24-240 VAC or 24-125 VDC, making it compatible with diverse marine electrical systems.

The actuator incorporates dry-contact closure outputs, allowing the vessel's control or monitoring system to confirm damper position at all times. The spring-return failsafe design automatically drives the connected fire damper toward its safe position if electrical power is lost, ensuring critical safety function during power interruptions. An integrated electro-thermal tripping device with a manually resettable mechanism at 165°F (72°C) provides thermal protection, and a test switch is included for operational verification.

The actuator is housed in a NEMA 2 / IP54 enclosure rated for marine environments and is CE approved for international compliance. Complete wiring harnesses and brackets are provided as part of the system, eliminating field assembly requirements. The entire damper system, including this actuator, is manufactured from marine-grade 316 stainless steel and built in the United States.

Key Features

• Failsafe electric actuation with spring-return design
• 180 in-lb closing torque for secure damper operation
• Wide voltage input range: 24-240 VAC or 24-125 VDC
• Dry-contact closure outputs for feedback confirmation
• NEMA 2 / IP54 enclosure for marine environments
• Integrated 165°F manually resettable thermal tripping device
• Included test switch for operational verification
• CE approved for international marine use
• USCG and MED approved as part of A60 damper system
• Manufactured and assembled in the United States
• 316 stainless steel construction
• Fast turnaround availability with 56 standard off-the-shelf sizes
