EATON ANL Fuse, Ignition Protected
The Bussmann series ANL current limiter is approved for use aboard gas-powered boats. Ignition protected when used in Bussmann series fuse blocks. The ANL limiter offers high amp ratings in a compact 7/8" x 3-3/16" size. Durable glass-laminated melamine body and riveted construction provides a rugged package and clear window provides visual indication. Tin-plated blades connect to 5/16" studs. Max 80V DC. Use with Bussmann SFR Fuse Blocks.
•2,700 Amp Interrupt Rating at max voltage satisfies ABYC requirements for main DC circuit protection on large battery banks
• Silver-plated connector blades for corrosion resistance
• Visible indication of blown fuse condition
• Ignition protected (conforming to SAE J1171)-safe for installation aboard gasoline powered boats (35-500 Amp only)
Key Features
- Approvals: Meets ISO 8846 Marine, RoHS, SAE J1171 Marine for ignition protection
- Ignition Protected: Yes. Devices, which operate in a potentially explosive environment, must be ignition protected. This would include engine rooms with gasoline engines. There is a very specific set of tests which a device must pass to claim ignition protection. They include operating safely in an explosive mixture of propane and air
- Maximum Voltage: 80V DC
- Interrupt Capacity, The fault current that a device, normally a fuse or circuit breaker is capable of breaking without damage: 2,700A @ 32V DC
