EGIS MOBILE ELECTRIC Dual ACR (Triple Battery), 2x, 80A, 12V

Two Independent ACRs in One Device reduce installation space and time. This significantly lowers the off-state current draw. Adjustable Auxiliary Battery Priority provides variable voltage points for each relay to share engine battery energy without sacrificing the ability to start.

Start/Engine Isolation and Start Assist functions are optional for each relay, allowing protection of sensitive electronics from engine-starting events or boosting cranking effectiveness.

Features:

Integrated sealed plug eliminates corrosion, included DT04 harness. A single device reduces installation time, space, cost, and points of potential failure
Ultra Low Off-State Current: Compare two typical ACRs (20 mA) vs Dual ACR @ 1.3 mA
Sealed unit, high-temperature materials allow mounting anywhere
Integrated thermal overload shutdown protection
Adjustable Off-Voltage for Auxiliary Battery Priority provides the ability to share start battery energy for auxiliary without risking engine starting ability
Start/Engine Isolation input option to ensure sensitive electronics do not experience voltage sags or spikes from the cranking event. Start Assist input option to ensure maximum cranking amps available when necessary
Nominal Voltage (Vdc): 12Vdc
Continuous Current Input: 160 Amps
Continuous Current Per Output: 80 Amps
Cable Size To Meet Ratings: 6 AWG/2 AWG
Maximum Cable Size: 2/0 AWG
Terminal Stud Size: M8x1.25
Hardware Material: Stainless Steel Self-Locking
Ingress Protection: IP65
Max Operating Temperature: 105 °C (221F)
Min Operating Temperature: -40C (-40F)
Operating Current (mA) Standby / Open: 1.3
Overvoltage Protection: 17 Vdc
