Bussmann Type III Class Thermal Circuit Breaker
Model #
17193004
Mfg #
SPA-187150L
$219.99
Orders placed by 3 PM EST typically ship the same day. Orders placed after this time will be processed the next business day.
Bussmann Type III Class Thermal Circuit Breaker
Model #
17193004
Mfg #
SPA-187150L
$219.99
Out Of Stock
Item out of stock get notified when back in stock:
Thank you!
We'll let you know when it's back in stock.
Quantity not available. Please adjust.
−
+
Complete Your Purchase
These Bussmann® breakers are available in 50, 70, 110 & 150 Amps sizes & are offered in surface-mount or thru-bulkhead versions. Thru-bulkhead models include a faceplate & install with a simple 2 1/8" holesaw cutout. All are IP66 for use in wet locations. Connections are 5/16" to accept large terminal lugs. All accept input voltage up to 48VDC.
- Switchable/manual reset
- Single lever
- Ignition protected
- Weather proof
- Mounting hole clearance for 5mm or 10-32 screws
- Robust 5/16-18 electrical termination studs in corrosion resistive materials
- Large clearance around studs to accept large gauge wire lugs
- All components meet SAE J1171 ignition protection
- Vapor proof
- Thru-bulkhead with panel & 12 Volts LED indicator light
- IP66 IP rating
- Voltage: 12 to 48VDC
- Amperage: 150 Amps
- Dimensions: 3 1/4" x 4 1/2"
- Hole Saw Cutout: 2 1/8"
- Terminals: 5/16"
- Case Material: Thermoset polyester
Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
Dimensions
3 1/4" x 2 1/2" x 4 1/2"
Type
Electrical Switchgear
Voltage
12 to 48 Volts DC
