TP10 TillerPilot

The TP10 TillerPilot fits a variety of tiller-steered sailboats up to 32' overall length.

The TP10 TillerPilot fits a wide variety of tiller-steered sailboats up to 32' overall length. Combining highly sophisticated electronics with advanced software and a powerful mechanical drive, it supplies reliable and accurate steering performance under a variety of conditions with minimal current consumption. The TillerPilots are simple to operate, using only five keys to access all functions, yet they represent the state-of-the-art in marine autopilots with many advanced features.

The simple and affordable TP10 does not include interfacing operation.

Key Features

• Easy To Use: A simple selection of controls enable straightforward selection of the adjustments you require.
• Precision Steering: Outstanding performance through a wide range of scenarios, even extreme weather, ensures the Pilot is positive and effective in typical coastal sailing conditions.
• Battery Optimization: Low power draw ensures your battery will last longer, even if you use the autopilot for prolonged periods.
• Silent Sailing: The TP range of autopilots have been designed with minimal noise in mind. They're extremely quiet, so you can enjoy the peaceful sensation of being out on the water.
• Waterproof Sealing: Protection from the elements.

 Specifications

• Maximum Boat Displacement: 10,000lb.
• Maximum Thrust: 143lb.
• Hardover Time: 6.9 seconds
• Drive Type: Screw thread
• NMEA 0183/SimNet: No
• Dimensions: 4"W x 2 3/16"H x 24"L (mid stroke)
• Voltage: 12V DC
• Power Consumption: 500mA (Auto); 60mA (Standby)
• Waterproof Rating: Mfr. rated waterproof

Optional Mounts

The TP10 requires brackets and estensions to ensure horizontally level mounting of the pilot at a 90° angle to the tiller. Order the size to fit your installation using the table below.
