5 MIDI/AMI Circuits with M8 Outputs Fuse Block
Model #
21481585
Mfg #
3908
$79.99
Orders placed by 3 PM EST typically ship the same day. Orders placed after this time will be processed the next business day.
5 MIDI/AMI Circuits with M8 Outputs Fuse Block
Model #
21481585
Mfg #
3908
$79.99
Out Of Stock
Item out of stock get notified when back in stock:
Thank you!
We'll let you know when it's back in stock.
Quantity not available. Please adjust.
−
+
Complete Your Purchase
EGIS MOBILE ELECTRIC 5 MIDI/AMI Circuits with M8 Outputs Fuse Block
Reduce Installation Space when combined with other Egis Mobile Electric power management devices and other sealed circuit breaker/fuse blocks. 5 MIDI/AMI circuits with M8 outputs. Expandable with Dual, Triple, and Quad Link Busbars for Plug-and-Play Install and Complete Switching/Protection Solutions.
Key Features
- Bullet-proof Construction: Sealed to IP66/IP6K9K, high temperature materials, Gore-Tex vent allows mounting anywhere. Stainless steel cable lug studs. Large mounting holes accept 1/4-20 / M6 attachment hardware.
- Protective Cover Stored 2 (Two) spare fuses and 4 (Four) screws. Easy to operate latching mechanism hold cover on securely
- SAE J1171 Ignition Protected
- Flex System Compatible with Flex interconnected busbars
- Voltage Range: 0-70Vdc
- Circuits: 5
- Maximum Total Current Per Block: 500 Amps
- Maximum MIDI / AMI Fuse Value: 200 Amps
- Ignition Protected: SAE J1171
- Ingress Protection Ratings: IP66, IP6K9K
- Max Vibration Withstand: 50g (10-2000Hz)
- Fastener Size For Mounting Holes: M6 or 1/4"
- Mounting Fastener Maximum Torque: 80 in-lbs
- Hardware Material: Stainless Steel Self-Locking
- Compatible with MINI / ATM Circuit Breaker: Yes
