M200 Marine Coaxial Speakers

The JL Audio® M200 marine speakers bring M-series audio to your boat for less, taking your onboard experience to the next level with high-quality sound. With 50- to 60-watt RMS power handling, the speakers deliver loud, clean sound with less distortion, while a silk-dome tweeter delivers smoother, warmer sound for all your cruises. Choose from 6.5" or 7.7" sizes with white or gray grilles, and add optional LED lighting to match your vessel's look.

Key Features

• High-quality coaxial marine speakers available in 6.5" and 7.7" sizes; sold as a pair
• 50- to 60-watt RMS power handling gives loud and clean sound with less distortion
• Bridge-mounted 1" edge-driven silk dome tweeter with a neodymium magnet and ferrofluid cooling delivers a smoother and warmer sound
• Injection-molded, mica-filled polypropylene cone for durable, consistent performance
• Optional RGB LED lighting enhances your audio experience with a wide spectrum of colors; pair with the Garmin Spectra™ control module (sold separately) for advanced lighting control from your compatible chartplotter or ActiveCaptain® app
• LED models are available in both sizes; 6.5" speakers are also available without lighting
• Choose White Sport or Gray Sport grilles, and customize your speakers with interchangeable grille options (sold separately)
• Marine-grade materials and finishes with corrosion-resistant connections and circuit boards withstand salt and sun
• IPX6 water rating protects against powerful spray and washdowns
• Surface-mount installation; mounting screws included

Specifications

6.5" Speakers

• Power handling: 50 W RMS
• Recommended amplifier power: 30 to 100 W RMS per channel
• Frequency response: 55 Hz to 20 kHz (±3 dB)
• Sensitivity: 87 dB (1 W/1 m)
• Nominal impedance: 4 ohms
• Diameter: 6.90" (175 mm)
• Overall depth: 4.19" (106 mm)
• Mounting depth: 2.83" (72 mm)
• Cutout: 5.00" to 5.25" (127 to 133 mm)

7.7" Speakers

• Power handling: 60 W RMS
• Recommended amplifier power: 40 to 100 W RMS per channel
• Frequency response: 45 Hz to 20 kHz (±3 dB)
• Sensitivity: 88 dB (1 W/1 m)
• Nominal impedance: 4 ohms
• Diameter: 7.70" (196 mm)
• Overall depth: 4.60" (117 mm)
• Mounting depth: 3.07" (78 mm)
• Cutout: 6.25" (159 mm)

All Models

• Speaker connections: Spade connectors
• LED supply voltage: 10 to 14.4 VDC (LED models)

What's Included

• One pair of speakers with grilles
• Mounting screws
• Documentation
• Two 0.25" and two 0.185" female crimpable connectors (non-LED models)
• Two water-resistant 6-pin connectors (LED models)

Installation Instructions
