Hook-4x Fishfinder with Dual Frequency Transducer

Top-of-the-line sonar technologies provide the best possible view of the environment beneath your boat.

Accurate CHIRP Sonar: It’s got CHIRP sonar built in, so you get a crisp view of fish, structure and the bottom. CHIRP provides more definition and better target separation than traditional sonar, giving you a clear view of what's down below. Enhanced sonar sensitivity, excellent target separation and superior noise rejection make seeing baitfish and gamefish targets easier. Full color LED-backlit displays are bright and clear in all lighting conditions, and all functions are controlled and accessed via a simple keypad.

Key Features

• CHIRP Sonar: The power of new and more accurate sonar to provide a better view beneath your boat
• Advanced Signal Processing (ASP) reduces the need to manually adjust settings to see fish, structure and bottom detail more clearly
• Convenient Page selector menu with quick access to all features using one-thumb operation
• Multi-Window Display lets you quickly choose from pre-set page layouts - including a three-panel view

What’s in the Box

• Hook-4x Fishfinder
• Dual-frequency transducer
• Power cable
• Documentation pack
• Fuse holder (ATC blade)
• Fuse

Specifications

• Display Type: 16-bit color TFT LCD
• Backlight: LED (11 levels)
• Screen Size: 4.3” diagonal
• Screen Resolution: 480 x 272
• Transducer: Dual-frequency transducer
• Frequency: Mid/High CHIRP (83/200kHz)
• Power Requirements: 12V DC
• Transmit Power: 500W (RMS)
• Dimensions: 3 13/16”W x 6 5/8”H x 2 3/16”D
• Power Requirement: 12V DC
• Voltage Input: 10 to 17V
• Amperage: Typical: 1.1A
• Fuse: 3A
• Waterproof Rating: IPX7
• Warranty: One year

Owner's Manual

Installation Guide

Optional Accessories (Sold Separately)
