EV-1 Sensor Core
Model #
14842884
Mfg #
E70096
$899.99
Orders placed by 3 PM EST typically ship the same day. Orders placed after this time will be processed the next business day.
Out Of Stock
Item out of stock get notified when back in stock:
Thank you!
We'll let you know when it's back in stock.
Quantity not available. Please adjust.
−
+
Complete Your Purchase
Designed for the latest drive-by-wire steering systems
- Nominal supply voltage: 12 V (powered by SeaTalkng system)
- Operating voltage range: 10.8 V to 15.6 V dc
- Power consumption (taken from SeaTalkng system): 30 mA
- SeaTalkng LEN (Load Equivalency Number): 1
- Sensors
3-axis digital accelerometer
3-axis digital compass
3-axis gyro digital angular rate sensor
- Data connections:
SeaTalkng
NMEA 2000 DeviceNet (EV-2 only) - Installation environmental:
Operating temperature: -20ºC to +55ºC (-4ºF to +131ºF)
Storage temperature: -30ºC to +70ºC (-22ºF to +158ºF)
Relative humidity: max 93%
Waterprrof rating: IPX 6 - Dimensions:
Diameter: 140 mm (5.5 in)
Depth (including mounting enclosure): 35 mm (1.4 in)
Depth (including wall bracket): 95 mm (3.8 in) - Weight:
0.29 kg (0.64 lbs) - EMC compliance
Europe: 2004/108/EC
Australia and New Zealand
Type
Sensors
Type
Sensors
