Mini Breaker Disconnect Switch, Panel Mount
Model #
22330971
Mfg #
4701-30
$39.99
Orders placed by 3 PM EST typically ship the same day. Orders placed after this time will be processed the next business day.
MADE IN THE USA
Mini Breaker Disconnect Switch, Panel Mount
Model #
22330971
Mfg #
4701-30
$39.99
Amperage:
30 Amp
Out Of Stock
Item out of stock get notified when back in stock:
Thank you!
We'll let you know when it's back in stock.
Quantity not available. Please adjust.
−
+
Complete Your Purchase
SEAFIT
$1.99
-
$2.99
Price reduced from
$11.49
to
-
Price reduced from
$16.49
to
EGIS MOBILE ELECTRIC Mini Breaker Disconnect Switch, Panel Mount
2-in-1 Circuit Breaker / Disconnect Switch incorporates traditional battery disconnect switching (Non-engine) and circuit protection. 42 Max Vdc rating easily supports 12, 24, and 36V systems. Ideal for trolling motor circuit switching applications.
Key Features
- Harsh Environment design with shock and vibration resistanc,e ideal for marine and vehicle electrical systems
- Weatherproof Against Dust & Water Intrusion to ensure reliable circuit protection for the life of the electrical system installation
- SAE & ABYC Compliant ensures compliance to meet the needs for modern vehicle and vessel installations
- Max Voltage: 42Vdc
- Short Circuit Interrupt Rating: 3kA/U3 per ABYC at 14Vdc
- Short Circuit Interrupt Rating: 1.5kA/U3 per ABYC at 28Vdc
- Hardware Material: Stainless Steel
- Terminal Stud Size: 1/4"-28
- Ingress Protection: IP66/IP67 (Flush Mount)
- Max Operating Temperature: 60°C / 140°F
- Min Operating Temperature: -40°C / -40°F
- Ignition Protection: ISO 8846, USCG, ABYC, UL110,7 UL150,0 and SAE J1171
- Mechanical Vibration: UL1107 at 100% rated current
- Mechanical Shock: UL1107 at 100% rated current
