HARKEN YACHT FITTINGS 60 mm Tulip Crossover Block
Crossover blocks provide a cleaner, more efficient deck by enabling sailors to route multiple lines to the winch on the opposite side with minimal hardware. These easy-to-install blocks mount behind the stopper bank on each side of the cabin house. The tulip sheave design is particularly effective as lead angles become more acute, offering superior performance compared to standard sheave shapes.
Each block features built-in risers and sculpted backing plates that distribute loads effectively and protect cored decks from concentrated pressure. The large, strong bases ensure durability and reliability in demanding marine environments. The 60 mm size is ideal for larger cruising and racing yachts requiring robust line management solutions.
Key Features
- 60 mm tulip sheave for optimal performance at acute lead angles
- Built-in risers and sculpted backing plates for load distribution
- Large, strong base design protects cored decks
- Maximum working load of 1361 kg (3000 lb)
- Breaking load of 2721 kg (6000 lb)
- Accepts line diameter up to 14 mm (9/16 in)
- Compact height of 48 mm (1 7/8 in)
- Weight of only 305 g (10.8 oz)
- Easy installation on existing deck layouts
