490MAM10 Spin-On Diesel Fuel/Water Separator, 10 Micron

490MAM10 Spin-On Diesel Fuel/Water Separator, 10 Micron

5 out of 5 Customer Rating
  • In Stock
Fulfilled by Vendor, typically 2-3 weeks.

Vendor Shipping Details

This item will be fulfilled from the vendor. Delivery time varies – typically 2–3 weeks.

Restrictions: This item does not ship to a PO Box, APO, FPO, DPO or international address. Expedited shipping is not available.

West Marine will email you when your order ships from the vendor.

This item is currently unavailable.
Enter your email address to be added to the waitlist.
Model # 17076548 Mfg # 490MAM10
Truck Freight

Truck Freight is used to ship items that exceed standard shipping limitations on weight and/or size. Delivery is only applicable within the contiguous United States. Additional shipping fees apply. Signature required for receipt of shipment.

Warning Hazard shipping
Item Can only Ship to Store

Fuel filter and water separators that make maintenance easy

Regardless of how carefully fuel is handled, dirt and water manage to find their way into your tank. A fuel filter/ water separator traps contaminates before they damage injectors and other sensitive engine parts. For almost 50 years, Racor has been a leading force in removing harmful debris and water from fuels.

The 400 Series fuel filter/water separators share a compact design and can be engine mounted or mounted to a bulkhead. Each 409MAM10 assembly includes a corrosion resisting powder coated cast aluminum mount head, 10 micron filter element, and bowl. Each Spin-On element features Aquabloc® which removes nearly 100% of the water by repelling moisture and directing it downward into the bowl where it can be drained safely with larger particulates through a 1/8" drain plug. Deep pleats in the filter media trap debris and help to extended service life. Filter element bodies are easy to grip for removal and installation. We recommend having spares aboard in preparation for unexpected clogs caused by tainted fuel from the dock or tank debris and algae stirred up by rough seas.

Key Features

  • Compact design provides more installation options
  • Spin-On design makes changing filter elements quick and easy
  • Integral priming pump makes filter speeds up filter changes
  • Aquabloc® removes almost 100% of water and moisture contaminates
  • Deep pleats in the element trap particulates and extend filter service life
  • Cast aluminum head provides excellent support for filter element and bowl
  • includes 10 micron filter element
  • Metal bowl meets ABYC and USCG heat test requirements for installation within engine rooms
  • Water sensor port in bowl for installation of optional water alarm


  • Application: Diesel
  • Flow Rate: 90 gph
  • Port Size: Four 1/4"-18 NPTF
  • Priming Pump: Yes
  • Drain: Yes
  • Dimensions: 12 7/8"H x 4 1/2"W x 4 7/8"D
Application Diesel
Dimensions 4 1/2" Width x 12 3/4" Height x 4 3/4" Depth
Features 10 Micron Filter
Type Fuel/Water Separators
