HARKEN YACHT FITTINGS Gizmo 12 mm Double Through-Deck Bushing
Double through-deck bushings are more structural than single through-deck bushings and can handle non-fair leads or loading on both sides of the deck. They thread into themselves from the top and bottom of the deck, making them exceptionally reliable for demanding marine applications. The Gizmo 12 mm Double Through-Deck Bushing is perfect for installing soft-attach loops to protect line from wear and also to separate line.
This bushing is manufactured from anodized aluminum, providing excellent corrosion resistance and durability in saltwater environments. It is designed for deck thickness between 13–18 mm (0.512–0.709 in) and features a maximum working load of 1,500 kg (3,300 lb), making it suitable for a wide range of sailing applications from dinghy to cruising vessels.
Key Features
- 12 mm center hole diameter for soft-attach loops and line separation
- Designed for deck thickness 13–18 mm (0.512–0.709 in)
- Anodized aluminum construction for corrosion resistance
- Maximum working load: 1,500 kg (3,300 lb)
- Double-sided threading for structural integrity
- Flange diameter: 41 mm (1.61 in)
- Drill size: 22 mm (7/8 in)
